What is miXtron?
miXtron is a pump, dosing and mixing hydraulic tool powered solely by water as driving force.
The pump is installed directly in the water supply line and allows users to create an homogenised solution always proportional to the volume of water regardless of changes in flow or pressure. These pumps require no electrical power, no water meter and no wires.
The global growth of intensive cultivations as well as water treatment systems, led miXtron to develop a range of medium flow proportional volumetric dosing pumps, characterised by technical innovative solutions, and high resistance materials aimed at providing dosing with maximum precision and reliability, even in the most critical environmental conditions.
How does it work?
 |
The water flow activates Mixtron pump |
 |
The additive at the desired percentage is mixed to water creating an homogenised solution |
 |
The solution is pushed downstream by the water pressure |
Whether a drinking water, water purification, osmosis or desalination system, precision and constant additive mixing is a crucial part of the treatment and final results.
These are the priorities that led us create a product that exceeds the technical and quality standards of proportional volumetric dosers now on the market.
Now we stock the miXtron Pedestal Water Powered Dosing Pump!
-1.png?width=348&name=VOLUMETRIC%20PROPORTIONAL%20DOSING%20PUMP%20WITH%20BUILT-IN%20BY-PASS%20%20(1)-1.png)
-
Water powered dosing pumps, Water powered proportional dosing pumps, Water driven dosing pumps, Water driven proportional dosing pumps, Fertiliser Injector
-
Dosing Ratio: 0.5 – 5 % of water flow rate
-
Operating Pressure: 0.3 – 8 bar (max 10 bar static)
-
Water temp: 5 – 40°C
Water Flow Rates
-
Model MX 1100 P055 B (1 – 11,000 l/hr, 11 m3/hr max)
-
Model MX 1300 P055 B (1 – 13,000 l/hr, 13 m3/hr max)
Thanks to its easy installation and size, our MXW series is the best choice for those who must guarantee accurate additive dosing and constant operations over time using water pressure and flow as the sole driving forces.
For more information, contact us today!
